10 Way 13A Sequential Start Vertical Illuminated Main Switch 13A Plug PDU
£263.16 Excl. VAT
Part No. 3273/13
• Power distribution unit for vertical mounting in 19″ panels with illuminated on/off switch and ten 13A UK sockets. When the panel is switched on the first two sockets energise followed by pairs of sockets at 1 second intervals
• A robust mild steel construction with Anthracite RAL 7016 paint finish
• Illuminated 2 pole on-off switch rated 16A with shroud protection
• Ten 13A UK sockets
• Internal wiring 2.5mm² – 20A rating
• High-Integrity dual earthing and external M5 earth stud with 250mm long earth lead for maximum safety
• Voltage 230V AC
• The first 2 sockets switch on together, followed by 4 pairs at 1 sec intervals
- Additional information
Additional information
Product Range | Vertical Sequential Start |
---|---|
Orientation | Vertical |
Socket Outlet Type | UK 13A |
Number of Sockets | 10 |
Neon | Yes |
Switched | Main Switch |
Fuse Holder | No |
Individually Fused | No |
Cable Length | 2M |
Plug Inlet Type | |
Colour | Anthracite (RAL 7016) |
Current Rating | 13A max |
Operating Voltage | Normal Operating Voltage: 230VAC – Maximum Operating Voltage: 250VAC |
Manufactured To | BS 5733 |
Socket Outlet Compliance | 13 Amp Sockets – BS 1363 |
UKCA / CE Compliant | Yes |
RoHs Compliant | Yes |
Country of Manufacture | United Kingdom |
Weight KGs | 3.58 |
Height (mm) | 1300 |
Width (mm) | 62 |
Depth (mm) | 40 |
Digital Power Meter | None |
