4 Way 32A Sequential Start Wieland Master Module Circuit Breaker Direct Wire PDU

4 Way 32A Sequential Start Wieland Master Module Circuit Breaker Direct Wire PDU

£459.36 Excl. VAT

In stock

£459.36 Excl. VAT

Part No. 444/32

• Sequential Master with 4 Wieland Connectors switched at 1 sec intervals
• Four Wieland sockets are switched on at 1 second intervals minimising high in-rush currents
• Module protected with 32A double pole MCB type C and protective cover (MCB brands may vary)
• All metal construction finished in black
• High integrity dual earthing
• Voltage 230V AC
• Current 32A max
• All metal construction
• Overall dimensions 105x200x377mm
• Matching Wieland connectors are available separately
• Patent No. GB2390237
• Timing module  –  EN 50081-1/2  EN 50082-2 CE UL
• This product is used with EXISTING power distribution units. When fitted in line with existing units, the module automatically switches each unit on in line at one second intervals, providing all the benefits of Sequential Start technology WITHOUT having to change your existing units (see diagram)

CompareCompare

Additional information

Product Range

Sequential Start Master Modules / Desk Cable Management

Orientation

Horizontal

Socket Outlet Type

Wieland Outlet

Number of Sockets

4

Neon

No

Switched

Main Switch

Individually Fused

No

Cable Length

No Cable Supplied

Plug Inlet Type

Colour

Black (RAL 9005)

Current Rating

32A max

Operating Voltage

Normal Operating Voltage: 230VAC – Maximum Operating Voltage: 250VAC

Manufactured To

BS 5733 and BS 6396

Cable Compliance

BS 6500

UKCA / CE Compliant

Yes

RoHs Compliant

Yes

Country of Manufacture

United Kingdom

Weight KGs

3

Height (mm)

377

Width (mm)

200

Depth (mm)

105

Digital Power Meter

None
