8 Way 19″ 1.5U Power Metered 10A IEC 60320 C13 Fused 32A Plug PDU
£250.05 Excl. VAT
Part No. PM1040/2F/32
- A robust mild steel construction with light grey (RAL 7035) finish
- 19″ 1.5U (66.6mm) high
- 8 IEC 60320 C13 10A shuttered sockets
- 2x 16A panel mounted fuses rated for the 32A plug
- Identity strip for marking individual circuits
- High-Integrity dual earthing and external M5 earth stud with 250mm long earth lead for maximum safety
- A digital meter with easy to read 9.4mm high digits
The Deluxe Power Meter Features:
Compare
- Additional information
Additional information
| Previous Part No. | AM1040/32 – PM1040/32 |
|---|---|
| Product Range | Meter Range |
| Orientation | Horizontal |
| Socket Outlet Type | C13 10A IEC 60320 |
| Number of Sockets | 8 |
| Neon | No |
| Switched | Unswitched |
| Fuse Holder | Yes |
| Fuse Rating | 16A |
| Individually Fused | No |
| Cable Length | 3M |
| Plug Inlet Type | |
| Colour | Light Grey (RAL 7035) |
| Current Rating | 16A max |
| Operating Voltage | Normal Operating Voltage: 230VAC – Maximum Operating Voltage: 250VAC |
| Manufactured To | BS 5733 |
| Socket Outlet Compliance | CSA, IEC 60320 C13 BEAB, UL, VDE |
| Cable Compliance | BS 6500 |
| UKCA / CE Compliant | Yes |
| RoHs Compliant | Yes |
| Country of Manufacture | United Kingdom |
| Weight KGs | 2.41 |
| Height (mm) | 66.6 (1.5U) |
| Width (mm) | 482.6 (19") |
| Depth (mm) | 70 |
| Digital Power Meter | Digital Power Meter |
