12 Way 13A Sockets Angled Right RF Filtered Surge Protected Illuminated Main Switch PDU

12 Way 13A Sockets Angled Right RF Filtered Surge Protected Illuminated Main Switch PDU

£207.80 Excl. VAT

In stock

£207.80 Excl. VAT

Part No. FU12RH/MS

  • Illuminated double pole incoming power switch
  • Strong steel case finished in light grey RAL 7035
  • Terminated with 2m of 3 core 1.5mm² cable and 13A fused plug
  • Internal wiring 2.5mm² rated 20A
  • Earth bonding for maximum safety
  • External M5 earth stud with 250mm earth lead
  • The essential power distribution source for 19″ rack mounting systems
  • The 45 degree angled sockets allow easy, tidy installation

Surge Filter:

  • All modes L-N, L-E, N-E
  • Maximum operating voltage – 275V rms ac
  • Transient energy absorption – 3 x 140J
  • Transient peak current – (8/20uS) – 6500A
  • Impulse response time – <50nS
  • Varistor voltage @ 1mA dc test current – 430V
  • Maximum clamping voltage @ 100A (8/20uS) – 710V

    • RF Filter:

  • Operating voltage up to 250V at max 400Hz
  • Filter rated current 10A @ 400ºC, 11.5A @ 25ºC
  • Leakage current 2 x 0.2mA max @ 220V 50Hz
  • Fitted with ZNR voltage transient and earthline choke
  • Standard spec. Z280G
  • Max continuous voltage 320V AC rms @ 25ºC
  • Max continuous voltage 416V DC @25ºC
  • Varistor 450V min @ 1mA
  • Energy 140 Joules 10/10000
  • 800V clamping voltage @ 100A
  • Max 800mW continuous
  • UL, CSA, VDE
    • Compare

    Additional information

    Product Range

    13A with Sockets Angled 45? Left or Right with Filter
    Orientation

    Vertical
    Socket Outlet Type

    UK 13A
    Number of Sockets

    12
    Neon

    Yes
    Switched

    Main Switch
    Fuse Holder

    No
    Individually Fused

    No
    Cable Length

    2M
    Plug Inlet Type

    Colour

    Light Grey (RAL 7035)
    Current Rating

    13A max
    Operating Voltage

    Normal Operating Voltage: 230VAC – Maximum Operating Voltage: 250VAC
    Manufactured To

    BS 5733
    Socket Outlet Compliance

    13 Amp Sockets – BS 1363
    Cable Compliance

    BS 6500
    UKCA / CE Compliant

    Yes
    RoHs Compliant

    Yes
    Country of Manufacture

    United Kingdom
    Weight KGs

    3.05
    Height (mm)

    1112
    Width (mm)

    62
    Depth (mm)

    40
    Digital Power Meter

    None
