5 Way 19″ 1.5U 13A Power Metered Illuminated Main Switch Sequential Start 16A Plug PDU

5 Way 19″ 1.5U 13A Power Metered Illuminated Main Switch Sequential Start 16A Plug PDU

£257.10 Excl. VAT

In stock

£257.10 Excl. VAT

Part No. PM1030/16

  • Sequential start technology to reduce start-up surges with a choice of digital meters in a standard 19″ 1.5U high enclosure
  • Sequential start – the first socket powers immediately with the remainder powering at 1 second intervals
  • A robust mild steel construction with light grey (RAL 7035) finish
  • 19″ 1.5U (66.6mm) high
  • 13A unswitched sockets
  • Internal wiring 2.5mm² – 20A rating
  • High-Integrity dual earthing and external M5 earth stud with 250mm long earth lead for maximum safety
  • Illuminated mains double pole switch
  • 16A IEC309 (BS4343) plug with 3 metres of cable
  • A digital meter with easy to read 9.4mm high digits

The Deluxe Power Meter Features:

  • Monitor Amps, volts, watts and P.F. (all True RMS)
  • The ability to either automatically scroll through the four values or to select the parameter to be displayed
  • 4x LEDs to easily identify what parameter is being measured
  • Accuracy 1% amps, volts, 2% Watts, 3% P.F.
    • Compare

    Additional information

    Previous Part No.

    AM1030/16
    Product Range

    Meter Range
    Orientation

    Horizontal
    Socket Outlet Type

    UK 13A
    Number of Sockets

    5
    Neon

    Yes
    Switched

    Main Switch
    Fuse Holder

    No
    Individually Fused

    No
    Cable Length

    3M
    Plug Inlet Type

    Colour

    Light Grey (RAL 7035)
    Current Rating

    16A max
    Operating Voltage

    Normal Operating Voltage: 230VAC – Maximum Operating Voltage: 250VAC
    Manufactured To

    BS 5733
    Socket Outlet Compliance

    13 Amp Sockets – BS 1363
    Cable Compliance

    BS 6500
    UKCA / CE Compliant

    Yes
    RoHs Compliant

    Yes
    Country of Manufacture

    United Kingdom
    Weight KGs

    2.8
    Height (mm)

    66.6 (1.5U)
    Width (mm)

    482.6 (19")
    Depth (mm)

    73 (100 inc gland)
