12 Way 13A Power Metered Sockets Angled Right 32A Plug PDU
£253.04 Excl. VAT
Part No. PM12/RH/32
- A robust mild steel construction with light grey RAL 7035 paint finish
- For vertical “0U” rack mounting
- Internal wiring 4mm² – 32A rating
- High-Integrity dual earthing and external M5 earth stud with 250mm long earth lead for maximum safety
- The 45 degree angled sockets allow easy, tidy installation
- 3m of 3 core cable with a 32A IEC 60309 (IEC309 / BS4343 / Commando) plug
- A digital meter with easy to read 9.4mm high digits
The Deluxe Power Meter Features:
Compare
- Additional information
Additional information
| Previous Part No. | AM12/RH/32 |
|---|---|
| Product Range | Meter Range |
| Orientation | Vertical |
| Socket Outlet Type | UK 13A |
| Number of Sockets | 12 |
| Neon | No |
| Switched | Unswitched |
| Fuse Holder | No |
| Individually Fused | No |
| Cable Length | 3M |
| Plug Inlet Type | |
| Colour | Light Grey (RAL 7035) |
| Current Rating | 16A max |
| Operating Voltage | Normal Operating Voltage: 230VAC – Maximum Operating Voltage: 250VAC |
| Manufactured To | BS 5733 |
| Socket Outlet Compliance | 13 Amp Sockets – BS 1363 |
| Cable Compliance | BS 6500 |
| UKCA / CE Compliant | Yes |
| RoHs Compliant | Yes |
| Country of Manufacture | United Kingdom |
| Weight KGs | 4.6 |
| Height (mm) | 1114 |
| Width (mm) | 62 |
| Depth (mm) | 58 |
| Digital Power Meter | Digital Power Meter |
